3D
Yamaha receivers displaying this icon support 3D HDMI pass-through on HDMI from 3D-compatible Blu-ray, games and broadcast devices to 3D-compatible HDTVs. 3D provides a more engaging audio and video consumer experience when using a 3D-capable products and 3D media content. Note that special eyewear may be required for viewing 3D content.HDMI
HDMI (High-Definition Multimedia Interface) is the first and only industry-supported, uncompressed, all-digital audio/video interface. With the ability to deliver crystal-clear, all-digital audio and video via a single cable, HDMI dramatically simplifies cabling and helps provide consumers with the highest-quality home theater experience. HDMI can provide an interface between most audio/video sources, such as a set-top box, Blu-ray player, DVD player, or A/V receiver and a video monitor, such as a High Definition Television (HDTV), over a single cable. Depending on the model of product, HDMI can support standard, enhanced, or high-definition video, plus multi-channel digital audio on a single cable. It can support all currently-available compressed audio formats (such as Dolby Digital and DTS) and most newer HDMI devices can support lossless digital audio formats like Dolby® TrueHD and DTS-HD Master Audio™.
Specifications
Channels
7.1
RMS Output Power (20Hz - 20kHz)
RMS Output Power (1kHz)
90W x 7
Total Power (20Hz - 20kHz)
630W (1kHz)
Dolby TrueHD
•
Dolby Digital EX/ Dolby Pro Logic IIx
•
DTS-HD Master Audio
•
DTS-ES Discrete 6.1
•
DTS 96/24 / DTS Neo:6
•
High Quality Parts Allowed Sound Tuning for Optimum Performance
5th Foot w/ Anti-Resonance Technology (A.R.T. Wedge)
Low Jitter PLL Circuity
H-shape Cross Member Frame
Symmetrical Power Amplifier Layout
DAC on Pure Ground Circuitry with High Quality Burr-Brown DACs
Four SCENE Buttons
Pure Direct
(Direct Mode)
HD Radio Tuner
iPod Compatibility
• (With optional YDS-11/12)
Bluetooth Compatibility
• (With Optional YBA-10)
Compressed Music Enhancer
•
Neural Surround
XM HD Surround
SRS (Circle Surround II)
THX Processing
Sirius Satellite Radio Ready
XM Satellite Radio Ready
HDMI (In/Out)
(4 / 1)
i.Link (IEEE 1394)
Component Video (In/Out)
(2 / 1)
A/V Inputs (S-Video)
5 (Composite)
Digital Inputs/Outputs [O: Optical, C: Coaxial]
(O: 2, C: 2)
Front A/V with Digital Input
• (A/V Only)
Front Mini Input for Portables
17
Front USB Input For Flash Memory Drives
Network Receiver Functions
D/A Conversion
192 kHz/24-bit
Surround Programs
17
Night Listening Enhancer
DCDi Processing
Time Base Corrector
•
HDMI 3D Capable
•
HDMI Audio Return Channel (ARC)
•
HDMI CEC Functionality
•
HDMI Standby-through
• (can change inputs in standby)
Analog Video to HDMI Upconversion
• (with upscaling up to 1080p)
HDMI to HDMI Upscaling
HDMI Video Processing
HDMI Video Adjustments
Component Video Upconversion
S-Video Upconversion
Dialogue Lift
YPAO (w/Optimizer Microphone)
• (w/PEQ)
On-Screen Display (OSD)
•
Auto Power Down
•
Assignable Power Amp
• (Bi-amp)
Channel Expandability w/ Ext. Amp
Zone Speaker Terminals
Zone 2 Output
Zone 3 Output
Zone 4 Output
Zone Power Switching
Zone Remote Control
Web Browser Control
RS-232C Interface
+12V Trigger Output
IR Inputs/Outputs
Receiver Manager Software
Speaker A, B or A + B
Selectable Subwoofer Crossover
•
Multi-Channel Decoder Inputs
Pre-Out All Channels
Learning Remote Capability
Preset
Macro Command Capability
Product Dimensions (W x H x D)
17-1/8" x 6" x 14-3/8"
Product Weight (lbs.)
18.7
Shipping Dimensions (W X H X D)
21"x 8-7/8" x 17-1/2"
Shipping Weight (lbs.)
24.25
